SCS212AJTLL Discrete ROHM Semiconductor Diode 650 V 12A Surface Mount TO-263AB
| Place of Origin | Japan |
|---|---|
| Brand Name | Rohm Semiconductor |
| Certification | RoHS |
| Model Number | SCS212AJTLL |
| Minimum Order Quantity | 1000 PCS |
| Price | Negotiable |
| Packaging Details | 1000 PCS/Tape |
| Delivery Time | 2-3 DAYS |
| Payment Terms | L/C, D/A, D/P, T/T |
| Supply Ability | 3K PCS |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Number | SCS212AJTLL | Manufacturer | Rohm Semiconductor |
|---|---|---|---|
| Technology | SiC (Silicon Carbide) Schottky | Voltage - DC Reverse (Vr) (Max) | 650 V |
| Current - Average Rectified (Io) | 12A | Voltage - Forward (Vf) (Max) @ If | 1.55 V @ 12 A |
| Speed | No Recovery Time > 500mA (Io) | Reverse Recovery Time (trr) | 0 Ns |
| Current - Reverse Leakage @ Vr | 240 µA @ 600 V | Mounting Type | Surface Mount |
| Package / Case | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | Operating Temperature - Junction | 175°C (Max) |
| High Light | SCS212AJTLL,SCS212AJTLL ROHM Semiconductor,Discrete Semiconductor Products |
||
Product Description
SCS212AJTLL Diode 650 V 12A Surface Mount TO-263AB
Datasheet:SCS212AJTLL
| Category | Single Diodes |
| Mfr | Rohm Semiconductor |
| Product Status | Active |
| Technology | SiC (Silicon Carbide) Schottky |
| Voltage - DC Reverse (Vr) (Max) | 650 V |
| Current - Average Rectified (Io) | 12A |
| Voltage - Forward (Vf) (Max) @ If | 1.55 V @ 12 A |
| Speed | No Recovery Time > 500mA (Io) |
| Reverse Recovery Time (trr) | 0 ns |
| Current - Reverse Leakage @ Vr | 240 µA @ 600 V |
| Mounting Type | Surface Mount |
| Package / Case | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB |
| Supplier Device Package | TO-263AB |
| Operating Temperature - Junction | 175°C (Max) |
| Base Product Number | SCS212 |
FEATURES:
・Shorter recovery time
・Reduced temperature dependence
・High-speed switching possible
Applications
・PFC Boost Topology
・Secondary Side Rectification
・Data Center
・PV Power Conditioners
DataPicture:https://fscdn.rohm.com/en/products/databook/datasheet/discrete/sic/sbd/scs212aj-e.pdf
