IPP65R110CFDA Diode Transistor And Thyristor N-Channel 650 V 31.2A Tc 277.8W Tc PG-TO220-3
| Place of Origin | United States |
|---|---|
| Brand Name | Infineon Technologies |
| Certification | RoHS |
| Model Number | BUF420AW |
| Minimum Order Quantity | 50 PCS |
| Price | Negotiable |
| Packaging Details | 50 PCS/Tube |
| Delivery Time | 2-3 DAYS |
| Payment Terms | L/C, D/A, D/P, T/T |
| Supply Ability | 6K PCS |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Category | Single FETs, MOSFETs | Mfr | Infineon Technologies |
|---|---|---|---|
| Series | Automotive, AEC-Q101, CoolMOS™ | Product Status | Active |
| FET Type | N-Channel | Technology | MOSFET (Metal Oxide) |
| Drain To Source Voltage (Vdss) | 650 V | Current - Continuous Drain (Id) @ 25°C | 31.2A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V | Rds On (Max) @ Id, Vgs | 110mOhm @ 12.7A, 10V |
| Vgs(th) (Max) @ Id | 4.5V @ 1.3mA | Gate Charge (Qg) (Max) @ Vgs | 118 NC @ 10 V |
| Vgs (Max) | ±20V | Input Capacitance (Ciss) (Max) @ Vds | 3240 PF @ 100 V |
| Power Dissipation (Max) | 277.8W (Tc) | Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Through Hole | Supplier Device Package | PG-TO220-3 |
| Package / Case | TO-220-3 | Base Product Number | IPP65R110 |
| High Light | Diodes 650 V 31.2A Tc 277.8W IPP65R110CFDA,Diodes 650 V 31.2A 277.8W IPP65R110CFDA,Diodes 650 V 277.8W IPP65R110CFDA |
||
Product Description
IPP65R110CFDA N-Channel 650 V 31.2A (Tc) 277.8W (Tc) Through Hole PG-TO220-3
Features:
| Category | Single FETs, MOSFETs |
| Mfr | Infineon Technologies |
| Series | Automotive, AEC-Q101, CoolMOS |
| Product Status | Active |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 650 V |
| Current - Continuous Drain (Id) @ 25ﾂｰC | 31.2A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 110mOhm @ 12.7A, 10V |
| Vgs(th) (Max) @ Id | 4.5V @ 1.3mA |
| Gate Charge (Qg) (Max) @ Vgs | 118 nC @ 10 V |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 3240 pF @ 100 V |
| Power Dissipation (Max) | 277.8W (Tc) |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | PG-TO220-3 |
| Package / Case | TO-220-3 |
| Base Product Number | IPP65R110 |
Additional Resources
| ATTRIBUTE | DESCRIPTION |
| Other Names | IPP65R110CFDAAKSA1-ND |
| 448-IPP65R110CFDAAKSA1 | |
| SP000895234 | |
| Standard Package | 50 |
Data Picture:https://www.infineon.com/dgdl/Infineon-IPX65R110CFDA-DS-v02_00-en.pdf?fileId=db3a304336797ff90136ba7c820925a5
|
±
|
