EEEFK1E100R Smd 10uf 25v Electrolytic Capacitor Resistors Capacitors Inductors
| Place of Origin | JAPAN |
|---|---|
| Brand Name | PANASONIC |
| Certification | RoHS |
| Model Number | EEEFK1E100R |
| Minimum Order Quantity | 2000 PCS |
| Price | Negotiable |
| Packaging Details | 2000 PCS/Tape |
| Delivery Time | 2-3 DAYS |
| Payment Terms | L/C, D/A, D/P, T/T |
| Supply Ability | 10K PCS |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Number | EEEFK1E100R | Category | Aluminum Electrolytic Capacitors |
|---|---|---|---|
| Manufacturer | Panasonic | Series | FK |
| Package | Tape & Reel (TR)/Cut Tape (CT) | Capacitance | 10uF |
| Tolerance | ±20% | Voltage Rating | 25V |
| Impedance | 1.35 Ohms | Lifetime @ Temp. | 2000hrs@105℃ |
| Operating Temperature | -55℃~105℃ | Ripple Current @ High Frequency | 90mA@100KHz |
| Ripple Current @ Low Frequency | 67.5 MA @ 120 Hz | Size / Dimension | 0.157" Dia (4.00mm) |
| Height - Seated (Max) | 0.240" (6.10mm) | Surface Mount Land Size | 0.169" L X 0.169" W (4.30mm X 4.30mm) |
| High Light | 10uf 25v electrolytic capacitor,10uf capacitor 25v,10uf smd electrolytic capacitor |
||
Product Description
Datasheet:EEEFK1E100R
10 µF 20% 25 V Aluminum Electrolytic Capacitors Radial, Can - SMD 2000 Hrs @ 105°C
Features:
● Endurance:105 ℃ 2000 h to 5000 h
● Low impedance(40 % to 60 % less than FC series)
● Miniaturized (30 % to 50 % less than FC series)
● Vibration-proof product (30G guaranteed) is available upon request(ø6.3 ≦)
● AEC-Q200 compliant
● RoHS compliant
Description:
EEE-FK Aluminum Electrolytic Capacitors INACTIVE
Panasonic EEE-FK Series Aluminum Electrolytic Capacitors are AEC-Q200 qualified,
RoHS directive compliant and offer low impedance and an endurance of 3000h to 5000h
at +105°C. EEE-FK Capacitors offer a 3.3µF to 6800µF capacitance range and a 6.3VDC
to 100VDC voltage rating.
Quick Detail:
| Manufacturer | Panasonic Electronic Components |
| Manufacturer Product Number |
EEE-FK1E100R
|
| Description |
CAP ALUM 10UF 20% 25V SMD
|
| Detailed Description |
10 µF 25 V Aluminum Electrolytic Capacitors Radial, Can - SMD 2000 Hrs @ 105°C
|
Product Attributes:
|
TYPE
|
DESCRIPTION
|
|
Category
|
Aluminum Electrolytic Capacitors
|
|
Mfr
|
Panasonic Electronic Components
|
|
Series
|
FK
|
|
Product Status
|
Active
|
|
Capacitance
|
10 µF
|
|
Tolerance
|
±20%
|
|
Voltage - Rated
|
25 V
|
|
Lifetime @ Temp.
|
2000 Hrs @ 105°C
|
|
Operating Temperature
|
-55°C ~ 105°C
|
|
Polarization
|
Polar
|
|
Ratings
|
AEC-Q200
|
|
Applications
|
Automotive
|
|
Ripple Current @ Low Frequency
|
67.5 mA @ 120 Hz
|
|
Ripple Current @ High Frequency
|
90 mA @ 100 kHz
|
|
Impedance
|
1.35 Ohms
|
|
Size / Dimension
|
0.157" Dia (4.00mm)
|
|
Height - Seated (Max)
|
0.240" (6.10mm)
|
|
Surface Mount Land Size
|
0.169" L x 0.169" W (4.30mm x 4.30mm)
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
Radial, Can - SMD
|
|
Base Product Number
|
EEE-FK
|
Additional Resources:
| ATTRIBUTE | DESCRIPTION |
| Other Names |
EEEFK1E100R
|
|
Q7122414
|
|
|
PCE3795TR
|
|
|
PCE3795CT
|
|
|
PCE3795DKR
|
|
|
2266-EEE-FK1E100R
|
|
| Standard Package | 2000 |
