EEFGX0E471R Solid Polymer Electrolytic Capacitor 470 µF 2.5 V 2917 7343 Metric Aluminum
| Place of Origin | JAPAN |
|---|---|
| Brand Name | PANASONIC |
| Certification | RoHS |
| Model Number | EEFGX0E471R |
| Minimum Order Quantity | 3500 PCS |
| Price | Negotiable |
| Packaging Details | 3500 PCS/Tape |
| Delivery Time | 2-3 DAYS |
| Payment Terms | L/C, D/A, D/P, T/T |
| Supply Ability | 105K PCS |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Number | EEFGX0E471R | Category | Aluminum - Polymer Capacitors |
|---|---|---|---|
| Manufacturer | Panasonic | Series | SP-Cap GX |
| Dielectric Material | Polymer | Capacitance | 470uF |
| Tolerance | ±20% | Voltage Rating | 2.5V |
| Equivalent Series Resistance | 3mΩ@100kHz | Lifetime @ Temp. | 2000hrs@105℃ |
| Operaing Temperature | -55℃~105℃ | Ripple Current @ High Frequency | 10.2A@100kHz |
| Length | 7.3mm | Width | 4.3mm |
| Height | 2mm | ||
| High Light | EEFGX0E471R,solid polymer electrolytic capacitor,solid polymer aluminum capacitor |
||
Product Description
Datasheet:EEFGX0E471R
470uF 20% 2.5V Aluminum - Polymer Capacitors 2917 (7343 Metric) 3mOhm 2000 Hrs @ 105°C
Features:
● Large capacitance (560 μF max.)
● Super Low ESR (3 mΩ max.)
● Low ESL ( 3-terminals : 50 % less than 2-terminals) [Suffifi x : L]
● High ripple current (10200 mAr.m.s. max.)
● RoHS compliance, Halogen free
Description:
EEF-GX & EEF-LX Specialty Polymer Capacitors
Panasonic EEF-GX and EEF-LX Specialty Polymer Capacitors (SP-Caps) feature
capacitance ranges of 330µF to 560µF. The EEF-GX and EEF-LX SP-Caps offer stable
capacitance at higher frequencies and low ESR among polymer technology capacitors.
The EEF-GX and EEF-LX Series SP-Caps are reliable alternatives to tantalum capacitors.
Quick detail:
|
Manufacturer
|
Panasonic Electronic Components
|
|
Manufacturer Product Number
|
EEFGX0E471R
|
|
Description
|
CAP ALUM POLY 470UF 20% 2.5V SMD
|
|
Detailed Description
|
470 µF 2.5 V Aluminum - Polymer Capacitors 2917 (7343 Metric) 3mOhm 2000 Hrs @ 105°C
|
Product Attributes:
|
TYPE
|
DESCRIPTION
|
|
Category
|
Aluminum - Polymer Capacitors
|
|
Mfr
|
Panasonic Electronic Components
|
|
Series
|
SP-Cap GX
|
|
Product Status
|
Active
|
|
Type
|
Polymer
|
|
Capacitance
|
470 µF
|
|
Tolerance
|
±20%
|
|
Voltage - Rated
|
2.5 V
|
|
ESR (Equivalent Series Resistance)
|
3mOhm
|
|
Lifetime @ Temp.
|
2000 Hrs @ 105°C
|
|
Operating Temperature
|
-55°C ~ 105°C
|
|
Applications
|
General Purpose
|
|
Ripple Current @ High Frequency
|
10.2 A @ 100 kHz
|
|
Size / Dimension
|
0.287" L x 0.169" W (7.30mm x 4.30mm)
|
|
Height - Seated (Max)
|
0.079" (2.00mm)
|
|
Surface Mount Land Size
|
0.287" L x 0.169" W (7.30mm x 4.30mm)
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
2917 (7343 Metric)
|
|
Base Product Number
|
EEF-GX
|
Additional Resources:
| ATTRIBUTE | DESCRIPTION |
| Other Names |
P122634CT
|
|
P122634TR
|
|
|
EEFGX0E471R
|
|
|
P122634DKR
|
|
| Standard Package | 3500 |
